Marchesini 3/8" BSP Single Overcentre Valve Banjo Bolt Mounted

Marchesini 3/8" BSP Single Overcentre Valve Banjo Bolt Mounted

PRODUCT CODE: V0392/FLV STOCK: IN STOCK
Regular price
£67.69
Sale price
£67.69
Regular price
Sold out
Unit price
per

Marchesini 3/8" BSP Single Overcentre Valve Banjo Mounted

This load control valve is designed to regulate actuator movement and block it in one direction, ensuring smooth, controlled load descent while preventing cavitation and unintended movement due to load weight.

For easy and secure installation, the valve comes with a special screw connection, allowing it to be directly mounted onto the actuator, improving system efficiency and stability.

Constructed for durability and reliability, it features a zinc-plated steel body, hardened and ground internal components, and BUNA N standard seals. The guided poppet design ensures negligible leakage, while the standard pressure setting of 320 Bar provides secure load holding. To function correctly, the valve setting must be at least 1.3 times greater than the load pressure, ensuring proper closure under maximum load conditions.

For installation, connect V1 and V2 to the supply, C1 to the free-flow side of the actuator, and use the provided bolt to directly mount flange C2 to the actuator side where flow should be blocked.

Designed for secure actuator locking and precise load management, this load control valve is an essential component for hydraulic systems requiring safe and efficient motion control.

  • 3/8" BSP
  • 40LPM
  • 350 Bar
  • 1:4,5 Pilot Ratio

Product Description

VBCD 3/8” SE A FLV

*Please note, the images displayed may not be the true representation of the product.
